By the end of this course, you will be able to:
- Navigate the general layout of the CST STUDIO SUITE interface
- Generate CAD geometries within the native modeling interface
- Set up the project environment with the desired units, frequency settings, background materials and boundary conditions
- Understand the various material types that exist and how to define them
- Setup excitations using lumped elements and waveguide ports
- Setup result monitors to obtain 2D/3D field data
- Choose and set up the most appropriate solver and algorithm for high frequency applications.
- Run Time-Domain (FIT) and Frequency-Domain (FEM) simulations including parametric sweeps and optimizations.
- Analyze simulation results such as S-parameters, voltages, currents, 3D nearfields and Farfields.
- Extract data from the standard result set through the use of post- processing templates.
Notes:
- A Virtual Machine (VM) and the appropriate licenses will be provided for all classes. If you wish to use your own hardware, refer to the DS Certified Workstations and ensure the relevant products and licenses are properly installed prior to the class start.
- The class may be cancelled or postponed based on enrollment, refer to the Refund and Cancellation Policy for details.
